Invacare CS8 King Single Bed

Description

Purpose and Benefits

The Invacare CS8 Floorline Bed is an advanced, electrically operated bed designed to support adult patient care in supervised medical environments. Its ultra-low floor height and versatile positioning functions promote safety, comfort, and flexibility for both users and caregivers.

This bed is equipped with a range of features to support daily care, including independent adjustment of backrest and knee sections, a built-in base extension, and a one-button chair position. With a safe working load of 250 kg, it is suitable for a broad range of care needs. Available in both single and king single sizes, the CS8 Floorline Bed offers excellent clinical functionality in a compact, home-appropriate design.

Features

• Electrically adjustable platform height from 150 mm to 680 mm

• Backrest tilt up to 65° and knee bend adjustment up to 35°

• Trendelenberg and reverse Trendelenberg tilt up to 14°

• Four-sectioned mattress platform for optimal positioning and pressure care

• One-touch chair position button for simplified transitions

• Four soft contoured mattress retainer handles for secure mattress placement

• Integral 195 mm foot-end base extension for additional length

• Removable timber head and foot boards for easy access and cleaning

• Under-bed lighting to enhance safety at night

• Four Tente twin castors (75 mm), including four braked and four free-wheeling castors

• Optional ¾ length fold-down side rails available

Specifications

Model: King Single

• Safe Working Load: 250 kg

• Warranty: 10 years on bed frame, 3 years on electronics

• Overall Length: 211 cm

• Overall Length with Extension: 230.5 cm

• Overall Width: 109 cm

• Platform Height Range: 150 mm to 680 mm

• Mattress Size (Recommended): 106 cm x 198 cm

• Mattress Platform Length: 1980 mm

• Mattress Platform Width: 1060 mm

• Mattress Platform Height (Min–Max): 100 mm to 170 mm

• Backrest Angle: 0° to 65°

• Knee Bend Angle: 0° to 35°

• Tilt Adjustment: 0° to 14° (head and foot down)

Optional Accessories

• Invacare Self Help Pole

• Cobalt Health Bedside Cabinet Single Lock

• Folding Side Rails (Pair) – CS8 Bed Compatible

• Invacare IV Pole – CS8 Bed Compatible
